RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
440
innovators for industry
Parameters
(cont’d)
Code
(cont’d)
If Bit #0 = 1, then (only) the values recorded by
set_trigger/set_trigger4/set_trigger8 by one of the two measurement
channels (either channel 1 or 2) are backward transformed as z coordinates:
Bit #1 = 0: Values recorded by measurement channel 1 (
Signal1
) are
transferred to the PC using
Ptr1
and then backward
transformed as z coordinates.
Values recorded by measurement channel 2 (
Signal2
) are
transferred untransformed to the PC using
Ptr2
.
= 1: Values recorded by measurement channel 2 (
Signal2
) are
transferred to the PC using
Ptr1
and then backward
transformed as z coordinates.
Values recorded by measurement channel 1 (
Signal1
) are
transferred untransformed to the PC using
Ptr2
.
Bit #2 = 0: Offset to the focal length defined by set_defocus or
set_defocus_list is backward transformed.
Bit #3 = 0: ABC correction is backward transformed.
Bit #4 = 0: Offset to the z coordinate defined by set_offset_xyz or
set_offset_xyz_list is backward transformed.
Bit #5 Reserved.
Bit #31 Reserved.
