10 RTC6 Commands
439
innovators for industry
Parameters
(cont’d)
Code
(cont’d)
For Bit #0 = 0, the measurement value pairs recorded by
set_trigger/set_trigger4/set_trigger8 are backward transformed as
xy coordinates:
Bit #1 = 0: Values recorded by measurement channel 1 ( Signal1 ) are
transferred to the PC using Ptr1 and then backward
transformed as x coordinates.
Values recorded by measurement channel 2 ( Signal2 ) are
transferred to the PC using Ptr2 and then backward
transformed as y coordinates.
= 1: Values recorded by measurement channel 1 ( Signal1 ) are
transferred to the PC using Ptr1 and then backward
transformed as y coordinates.
Values recorded by measurement channel 2 ( Signal2 ) are
transferred to the PC using Ptr2 and then backward
transformed as x coordinates.
Bit #2 = 0: Gain/offset correction of automatic self-calibration is
backward transformed.
Bit #3 = 0: Image Field correction is backward transformed.
Bit #4 = 0: Offset of the defined coordinate transformation is
backward transformed.
Bit #5 = 0: Total matrix of the defined coordinate transformation is
backward transformed.
Bit #6 Reserved.
… …
Bit #31 Reserved.
Ctrl Command get_transform_offset
