10 RTC6 Commands
670
innovators for industry
Comments
(cont’d)
• For the RTC5/RTC6 predecessors, the laser control signal levels are defined by solder
jumpers. The RTC5/RTC6 lets users control them completely by software.
get_startstop_info queries the current status of the Laser Control Signals (Bit #9) and
whether the signals are set to active-HIGH or active-LOW (Bit #13).
• Enabling and disabling of Laser Control Signals can also be achieved by enable_laser
or disable_laser.
By get_startstop_info ( Bit #14 ) the current state can be queried.
• Even if the Laser Control Signals were enabled with set_laser_control or enable_laser,
they are not outputted without further commands, see Chapter 7.4 ”Laser Control”,
page 184.
• The phase shift of the Laser Control Signals (Bit #1 = 1) can be set for better
synchronization of an analog output, for example, in Softstart Mode (not yet
implemented) or the Pixel Output Mode, see Chapter 8.7 ”Pixel Output Mode”,
page 263.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
Last change DLL 617, OUT 617, RBF 623: get_startstop_info ( Bit #14 ) support.
References set_laser_mode, config_laser_signals
Ctrl Command set_laser_control
