Undelayed
Short List
Command
sub_call_abs_repeat
Function Causes an unconditional jump to an indexed subroutine and executes its body several
times.
Call sub_call_abs_repeat( Index, Number )
Parameters Index Index of the to be called indexed subroutine (as with sub_call_abs).
Number Number of repetitions.
0 is treated as 1.
As an unsigned 32-bit value.
Comments • sub_call_abs( Index ) is synonymous with sub_call_abs_repeat( Index, 1 ) .
• See sub_call_repeat and sub_call_abs.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References sub_call_repeat, sub_call_abs, sub_call
Undelayed
Short List
Command
sub_call_cond
Function Conditional call of an indexed subroutine: sub_call_cond executes sub_call( Index ), if the
current IOvalue at the 16-bit digital input port of the EXTENSION 1 socket connector meets
the following condition:
((IOvalue AND Mask1) = Mask1) AND (((not IOvalue) AND Mask0) = Mask0)
(= if the bits specified in Mask1 are 1 and the bits specified in Mask0 are 0 ). Otherwise, the
directly following list command is immediately executed.
Call sub_call_cond( Mask1, Mask0, Index )
Parameters Mask1 16-bit mask.
As an unsigned 32-bit value.
Only the lower 16 bits are evaluated.
Mask0 See Mask1 .
Index Index of the to-be-called indexed subroutine.
As an unsigned 32-bit value.
Allowed value range: [0…1023].
Comments • See sub_call.
• See also Chapter 9.3.2 ”Conditional Command Execution”, page 295.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References sub_call
