10 RTC6 Commands
806
innovators for industry
Undelayed
Short List
Command
switch_ioport
Function Executes a relative list jump list_jump_rel ( Pos ) whose jump distance Pos (>1) is
determined at runtime by the current value ( IOvalue ) at the 16-bit digital input port of the
EXTENSION 1 socket connector. You can specify which of the 16-bit digital input port’s bits
should be evaluated for this purpose.
Call switch_ioport( MaskBits, ShiftBits )
Parameters MaskBits Number of contiguous bits of the 16-bit digital input port to be
evaluated for determining the jump distance.
As an unsigned 32-bit value.
Allowed value range: [1…16].
ShiftBits Position of the least significant to-be-evaluated bit of the 16-bit digital
input port. As an unsigned 32-bit value.
Allowed value range: [0…15].
Comments • With invalid values of MaskBits or ShiftBits and with ( MaskBits + ShiftBits ) > 16,
switch_ioport is replaced by a list_nop (get_last_error return code
RTC6_PARAM_ERROR ).
• The following applies: Mask = ((1 << MaskBits ) – 1) << ShiftBits and
SwitchNo = ( Mask & IOvalue ) >> ShiftBits . Here, a list_jump_rel( Pos ) with
Pos = ( SwitchNo + 1) list positions are then executed.
• The jump distance is at least 1. This prevents infinite loops when no signal is present.
Jumps to the same address ( Pos = 0) are not possible with switch_ioport, but can be
simulated by list_jump_rel ( –1 ) as the directly subsequent command.
• The maximum jump distance is 2
16
list positions.
• See also list_jump_rel.
• See also Section ”16-Bit Digital Input Port and 16-Bit Digital Output Port”, page 78 and
Chapter 9.3.2 ”Conditional Command Execution”, page 295.
Example
(Pascal)
• It is assumed that the current value at the 16-bit digital input port is $F152 at runtime:
then switch_ioport( $0008, $0004 ) executes list_jump_rel( $0016 ), that is, a
relative list jump of length 22 list positions.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References list_jump_rel, list_jump_rel_cond
