16.1.2 System Requirements
Hardware
• Shielded housing with:
– Provisions for mechanical mounting, incl.
mounting hardware
– appropriate thermal coupling (cooling) of the
board
– Power outlet
– Ethernet cable
– Power supply as specified
– Cable with connector for powering the
RTC6 Ethernet Board
– Flat ribbon cables for peripheral equipment
(laser, scan head, extensions)
• Windows PC
• Gigabit Ethernet (preferred), 10/100 Mbit/s
Ethernet
Software
• TCP/IP protocol IPv4
• UDP protocol
• Used ports (default)
– 63749 (UDP)
– 63750 (UDP, TCP)
For the development of user programs:
• DLL/Import declarations (contained in
RTC6 Software Package)
Caution!
• To avoid interference coupling and emissions,
never operate the RTC6 Ethernet Board without
shielding (e.g. outside a metal housing).
• The RTC6 Ethernet Board is designed exclusively
for industrial use. It is intended for integration
in a machine (typically in a laser system) and
does not fulfill all requirements of a ready-to-
use consumer end product. Only operate the
RTC6 Ethernet Board after integration in a
machine meeting all applicable directives and
standards (of your local jurisdiction). It is not
suitable for use as a toy, in households or
inclement environments (e.g. outdoors). The
operator must take appropriate precautionary
measures to prevent such improper usage.
• Installation and commissioning should only be
performed by personnel with sufficient
qualifications, e.g. knowledge of electrical
equipment safety. Only perform installation and
maintenance if power and lasers are switched
off.
• Because the RTC6 Ethernet Board is a Class A
device capable of generating interference in
residential areas, the operator may be required
to carry out appropriate measures.
