RTC6 boards
Doc. Rev. 1.0.21 en-US
16 Appendix A: The RTC6 Ethernet Board
884
innovators for industry
77
LASER socket connector (detail, indicated by dashed line): input/output wiring plan.
TLE2142
+12V
74HC14
4k7
SN74LVC3G34
+5V
74HC14
4k7
SN74LVC1G126
+5V
TLE2142
+12V
+5V
74HC14
4k7
SN74LVC3G34
+5V
SN74LVC3G34
+5V
74HC14
4k7
SN74LVC1G126
+5V
SN74LVC1G126
+5V
10
1010
(16) NOT CONNECTED
(14) ANALOG OUT2
(12) GND
(10) DIGITAL IN1
(08) DIGITAL OUT1
(06) /STOP
(04) GND2
(02) LASER2
ANALOG OUT1 (15)
+5 V (13)
DIGITAL IN2 (11)
DIGITAL OUT2 (09)
BUSY OUT (07)
/START (05)
LASERON (03)
LASER1 (01)
On RTC6 boards without
“DC/DC”option
this jumper is closed.
On RTC6 boards without
“DC/DC” option the signals are
not galvanically decoupled and
GND2 = GND.
+3.3V
+3.3V
+3.3V
+3.3V
+3.3V
+3.3V
+3.3V
+3.3V
