RTC6 boards
Doc. Rev. 1.0.21 en-US
18 Appendix C: The RTC6 EtherBox
932
innovators for industry
18 Appendix C: The RTC6 EtherBox
93
RTC6 EtherBox. Dimensions. For example, #148520.
177 mm
51 mm
44 mm
221.5 mm
Suitable for top hat rail
complying to EN 60715
Do not obstruct
air circulation!
Do not obstruct
air circulation!
