20 Appendix E: iDRIVE Scan Systems – Control Commands and Signals Transmitted to RTC Boards
943
innovators for industry
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 01 As of scan system firmware  2001.
Actual position (angular position of galvanometer scanners)
16-bit
protocol
20-bit
protocol
Bit #0
…
Bit #15
Bit #0
…
Bit #19
Unit with 16-bit protocol: In bits.
Value range with 16-bit protocol: [–32.768…+32.767].
Unit with 20-bit protocol: In bits.
Value range with 20-bit protocol: –524.288…+524.287.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 02
As of scan system firmware  2001.
Set position (angular position of galvanometer scanners)
As of scan system firmware  5050.
With excelliSCAN scan heads:
Precalculated set position (angular position of galvanometer scanners).
Refer to “excelliSCAN Scan Heads – Functional Principle of SCANahead Servo
Control and Operation by RTC6 Boards” Manual, Chapter 3.1.7 ”excelliSCAN
Timing Diagram (Scan Head with SCANahead Control)”, page 16 and Figure 4.
16-bit
protocol
20-bit
protocol
Bit #0
…
Bit #15
Bit #0
…
Bit #19
Unit with 16-bit protocol: In bits.
Value range with 16-bit protocol: [–32.768…+32.767].
Unit with 20-bit protocol: In bits.
Value range with 20-bit protocol: –524.288…+524.287.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
