RTC6 boards
Doc. Rev. 1.0.21 en-US
20 Appendix E: iDRIVE Scan Systems – Control Commands and Signals Transmitted to RTC Boards
945
innovators for industry
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 05
As of scan system firmware  2001.
Relative galvanometer scanner control
Not intellicube.
16-bit
protocol
20-bit
protocol
Bit #0
…
Bit #15
Bit #0
…
Bit #19
Unit with 16-bit protocol: In per mille.
Value range with 16-bit protocol: [–1,000…+1,000].
Unit with 20-bit protocol: In 16
–1
per mille.
Value range with 20-bit protocol: [–16,000…+16,000].
The return value 16 entspricht 1‰.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 06 As of scan system firmware  2001.
Actual velocity (angular velocity)
16-bit
protocol
20-bit
protocol
Bit #0
…
Bit #15
Bit #0
…
Bit #19
Unit with 16-bit protocol: In Bit/ms.
Value range with 16-bit protocol: [–32.768…+32.767].
Unit with 20-bit protocol: In Bit/ms.
Value range with 20-bit protocol: –524.288…+524.287.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
