20 Appendix E: iDRIVE Scan Systems – Control Commands and Signals Transmitted to RTC Boards
964
innovators for industry
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 31 As of scan-system firmware  2061.
Running time (hours)
16-bit
protocol
20-bit
protocol
Bit #0
…
Bit #15
Bit #4
…
Bit #19
Unit with 16-bit protocol: In h.
Value range with 16-bit protocol: [0…23].
Unit with 20-bit protocol: In h.
Value range with 20-bit protocol: [0…23].
– Bit #0
…
Bit #3
= 0.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 32 As of scan-system firmware  2061.
Running time (days)
16-bit
protocol
20-bit
protocol
Bit #0
…
Bit #15
Bit #4
…
Bit #19
Unit with 16-bit protocol: In d.
Value range with 16-bit protocol: [0…65,535].
Unit with 20-bit protocol: In d.
Value range with 20-bit protocol: [0…65,535].
– Bit #0
…
Bit #3
= 0.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
