Scanlab RTC6 PCIe Board - Page 966

RTC6 boards
Doc. Rev. 1.0.21 en-US
20 Appendix E: iDRIVE Scan Systems – Control Commands and Signals Transmitted to RTC Boards
966
innovators for industry
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 35
As of scan system firmware  206x.
Only intelliWELD:
Purge gas flow rate
16-bit
protocol
20-bit
protocol
Bit #0
…
Bit #15
Bit #4
…
Bit #19
Unit with 16-bit protocol: [(purge gas flow rate – 4 l/min) *
109,89 min/l].
Value range with 16-bit protocol: [0…2,250].
Unit with 20-bit protocol: [purge gas flow rate – 4 l/min) *
109,89 min/l].
Value range with 20-bit protocol: [0…2,250].
– Bit #0
…
Bit #3
= 0.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
Code
HIGH
(hex)
Code
LOW
(hex)
Data type transmitted by the scan system
05 36 As of scan system firmware  206x.
Only intelliWELD:
[Temperature of mirror 2 + 26.6 °C]
16-bit
protocol
20-bit
protocol
Bit #0
…
Bit #15
Bit #4
…
Bit #19
Unit with 16-bit protocol: In 0.05 °C.
Value range with 16-bit protocol: [0…1,992].
Unit with 20-bit protocol: In 0.05 °C.
Value range with 20-bit protocol: [0…1,992].
– Bit #0
…
Bit #3
= 0.
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
