RM0008 Controller area network (bxCAN)
527/690
CAN bit timing register (CAN_BTR)
Address offset: 0x1C
Reset value: 0x0123 0000
Note: This register can only be accessed by the software when the CAN hardware is in
initialization mode.
Bits 6:4 LEC[2:0]: Last Error Code
This field is set by hardware and holds a code which indicates the error condition of the last error
detected on the CAN bus. If a message has been transferred (reception or transmission) without
error, this field will be cleared to ‘0’.
Code 7 is unused and may be written by the hardware to check for an update
000: No Error
001: Stuff Error
010: Form Error
011: Acknowledgment Error
100: Bit recessive Error
101: Bit dominant Error
110: CRC Error
111: Set by software
Bit 3 Reserved, forced by hardware to 0.
Bit 2 BOFF: Bus-Off Flag
This bit is set by hardware when it enters the bus-off state. The bus-off state is entered on TEC
overflow, greater than 255, refer to Section 21.4.6 on page 514.
Bit 1 EPVF: Error Passive Flag
This bit is set by hardware when the Error Passive limit has been reached (Receive Error Counter
or Transmit Error Counter>127).
Bit 0 EWGF: Error Warning Flag
This bit is set by hardware when the warning limit has been reached
(Receive Error Counter or Transmit Error Counter≥96).
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
SILM LBKM Reserved SJW[1:0] Res. TS2[2:0] TS1[3:0]
rw rw Res. rw rw rw rw rw rw rw rw rw
1514131211109876543210
Reserved BRP[9:0]
Res. rw rw rw rw rw rw rw rw rw rw
Bit 31 SILM: Silent Mode (Debug)
0: Normal operation
1: Silent Mode
Bit 30 LBKM: Loop Back Mode (Debug)
0: Loop Back Mode disabled
1: Loop Back Mode enabled
Bits 29:26 Reserved, forced by hardware to 0.
