Cisco NCS 2006 - Page 261

Input-Output Alarms - Left
Connector
Input Alarms - Right
Alarm Connector
Color CodePin Number
———
11
Output Pair #1 + or Input
Pair #11 +
Output Pair #3 + or Input
Pair #13 +
White/Gray12
Output Pair #2 + or Input
Pair #12 +
Output Pair #4 + or Input
Pair #14 +
Black/Gray13
Minor Audible Alarm -Input Pair #1 -Brown/Black14
Major Audible Alarm -Input Pair #2 -Red/Black15
Critical Audible Alarm -Input Pair #3 -Orange/Black16
Remote Audible Alarm -Input Pair #4 -Yellow/Black17
Minor Visual Alarm -Input Pair #5 -Green/Black18
Major Visual Alarm -Input Pair #6 -Blue/Black19
Critical Visual Alarm -Input Pair #7 -Blue/White20
Remote Visual Alarm -Input Pair #8 -Orange/White21
—
Input Pair #9 -Green/White22
Alarm Cutoff (ACO) -Input Pair #10 -Brown/White23
———
24
Output Pair #1 - or Input
Pair #11-
Output Pair #3 - or Input
Pair #13 -
Gray/White25
Output Pair #2 - or Input
Pair #12 -
Output Pair #4 - or Input
Pair #14 -
Gray/Black26
Table 14: SCSI Alarm Wire-Wrap Cable (15454-M-ALMCBL2) Connector Details
Input-Output Alarms - Left
Connector
Input Alarms - Right
Alarm Connector
Color CodePin Number
Minor Audible Alarm +Input Pair #1 +Black/Brown1
Major Audible Alarm +Input Pair #2 +Black/Red2
———
3
Cisco NCS 2000 Series Hardware Installation Guide
233
Connecting and Routing the Cables
DLP-L26 Installing Alarm Wires in NCS 2006
