TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 109
Basic hardware procedures
Figure 57: Mounting the side cover (tower server) (B)
Ê Close the locking lever on the side cover (1). This will slide the top cover shut
engaging the locking mechanism (2).
