Fujitsu PRIMERGY RX350 S8

742 Upgrade and Maintenance Manual TX300 S8 / RX350 S8
Cabling
16.2.5 Power cabling with 8x 3.5-inch HDDs and
4x 3.5-inch HDD extension box
Figure 581: Power cabling: 8x 3.5" HDDs and 4x 3.5" HDD extension box
System Board D2949
PSU CONTROL
PWR
Power Backplane
X25
X21
X20
X22 / X23
PWR HDD / ODD
4x 3.5-inch HDD
Backplane 1
X9
X10
X7
4x 3.5-inch HDD
Backplane 2
X9
X10
X7
P2
Drive Bays 1-3
4x 3.5-inch
HDD Extension Box
HDD Backplane
Slimline ODD
X7
X1
8A
P4
1
P1
