7.4.2 Installing the 2x 3.5-inch HDD extension box
7.4.2.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 125
Ê "Shutting down the server" on page 62
Ê "Disconnecting the server from the mains" on page 63.
Ê When working on a rack-mounted server:
"Extending / removing the server from the rack" on page 64
Ê "Opening the server" on page 68
Ê "Removing the system air duct" on page 81
Ê "Removing the system fan holder" on page 330
7.4.2.2 Removing accessible drive dummy covers
Ê Remove accessible drive filler covers from the required bays as described
in section "Accessible drive filler covers" on page 94.
Ê Remove accessible drive covers as described in section "Accessible drive
covers" on page 96.
7.4.2.3 Installing the slimline ODD and LSD module into the HDD
extension box
Ê If applicable, install the slimline ODD into the new 2x 3.5-inch HDD
extension box as described in section "Installing the slimline ODD into the
extension box" on page 571.
Ê If applicable, install the LSD module into the 2x 3.5-inch HDD extension box
as described in section "Installing the LSD module into the HDD extension
box" on page 575.
Upgrade and Repair Unit
(URU)
Average task duration:
10 minutes
Tools: Slotted screw driver (for bending in or out accessible drive mounting
brackets)
