Fujitsu PRIMERGY RX350 S8

760 Upgrade and Maintenance Manual TX300 S8 / RX350 S8
Cabling
16.2.24 SAS 3.0 FBU cabling
Figure 600: SAS 3.0 FBU cabling
16.2.25 Modular LAN NCSI sideband cabling
Figure 601: Modular LAN NCSI sideband cabling
FBU 03 (middle)
FBU 03 (bottom)
FBU 03 (top)
SAS 3.0 Controller
(PCI Slot 10)
MLC 1
MLC 2
PRAID
30
System Board D2949
Modular LAN
Controller
NC-SI 24
