Fujitsu PRIMERGY RX350 S8

TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 749
Cabling
16.2.12 Power cabling with 16x / 24x 2.5-inch HDDs / SSDs
and backup drives
Figure 588: Power cabling: 16x / 24x 2.5" HDDs / SSDs and backup drives
4x 2.5-inch HDD
Backplane 1
X6 (SAS 2.0) / X10 (SAS 3.0)
X9 (SAS 2.0) / X14 (SAS 3.0)
P2
4x 2.5-inch HDD
Backplane 3
X6
X9
4x 2.5-inch HDD
Backplane 4
X6
X9
Drive Bay 1
Drive Bay 2
Drive Bay 3
Optical Disk Drive
USB Backup Drive
SAS Backup Drive
System Board D2949
PSU CONTROL
PWR
PWR HDD / ODD
Drive Bays 2-3
8x 2.5-inch
HDD Extension Box
Backplane 6
X8
Backplane 5
X8
5
3
6
P3
1
Power Backplane
X21
X25
X20
X22 / X23
P4
4x 2.5-inch HDD
Backplane 2
X6 (SAS 2.0) / X10 (SAS 3.0)
X9 (SAS 2.0) / X14 (SAS 3.0)
P1
3
5 / 7
