Ê Connect the cable end on the FBU module to the FBU adapter cable as
shown:
9.6.3.4 Installing the FBU holder into the chassis
Figure 345: Mounting the FBU holder (A)
I Note the positions of the fixation bolts on the chassis floor (A-C) and
corresponding keyhole slots on the FBU holder.
RAID controller / TFM module TFM adapter cable Cabling plan
D3116 SAS RAID controller
TFM (LSZ:L3-25419-01)
T26139-Y4032-V1 16.2.23
D3216 PRAID EP400i
SAS 3.0 RAID controller
TFM 4G (LSZ:03-25444-05)
T26139-Y4031-V103 16.2.24
D3216 PRAID EP420i
SAS 3.0 RAID controller
TFM 8G (LSZ:03-25444-01)
