Ê Insert the perforated drive cover modules into drive bays 1 and 2 and
carefully push in until they are flush with the server front (2).
Figure 320: Installing perforated drive cover modules (B)
Ê Close the locking bar until it locks in place.
9.4.2.12 Concluding steps
Ê "Closing the server" on page 98
Ê When working on a rack-mounted server:
"Mounting the server in the rack" on page 115
Ê Reconnect all external cables to the replaced expansion card.
Ê "Connecting the server to the mains" on page 118
Ê "Enabling SVOM boot watchdog functionality" on page 146
Ê If BitLocker functionality is used and has been disabled before starting the
maintenance task: "Resuming BitLocker functionality" on page 152
