TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 769
17 Appendix
17.1 Mechanical overview
17.1.1 Server front
2.5-inch HDD / SSD model
Figure 610: PRIMERGY TX300 S8 / RX350 S8 front - 2.5-inch HDD / SSD model
Pos. Component Reference
1
2.5-inch hard disk drives /
solid state drives / dummy
modules
"8x 2.5-inch HDDs / SSDs
(2 SAS backplanes)" on page 189
2
Optical disk drive /
5.25-inch dummy module
"Accessible drive bays" on page 530
3ID card "Opening the server" on page 68
