12.2.4.2 USB backup drive
I Notes on RDX drive USB cabling:
– A USB 2.0 RDX drive may be replaced by a USB 3.0 RDX drive with
previous cabling.
– A USB 3.0 RDX drive may be connected to a USB 2.0 cable with
limited performance.
– A USB 3.0 RDX drive may be connected to an onboard USB 2.0
connector with limited performance.
– For full performance, connect the USB 3.0 RDX drive to a USB 3.0
PCI interface card by USB 3.0 cable.
– The USB 3.0 cable cannot be connected to a USB 2.0 RDX drive.
3.5-inch HDD configurations
Cable
(T26139-)
Cabling
list no.
from to
Cabling
plan
USB 2.0 cable
Y3973-V96
21A
USB backup drive
(Type B connector)
System board
connector USB INT 1
(6-pin connector)
16.2.1
USB 3.0 cable
Y4039-V100
21B
USB 3.0 PCI card
(Type A connector)
Backup drive power
cable
Y4029-V1
5
USB backup drive
(PATA connector)
3.5-inch HDD
backplane 1
connector X10
(4-pin connector)
16.2.3
