TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 757
Cabling
16.2.21 Cabling of standard GPGPU / coprocessor cards
Figure 597: Standard GPGPU / coprocessor card cabling
System Board D2949
PSU CONTROL
PWR
GPGPU Card 1
PWR HDD / ODD
GPGPU Card 2
Power Backplane
X25
X21
X20
X22
4x 3.5-inch HDD
Backplane 1
X9
X10
X7
4x 3.5-inch HDD
Backplane 2
X9
X10
X7
24
PWRPB
PWR 1
P2
P1
X23
25 25
P3
P4
1
