16.1 List of used cables
I The numbers in the cable list correspond to those shown in the cabling
plans below.
No. Name Length
Number
(T26139-)
Routing
1 HDD Power Cable
750 / 550 /
450 mm
Y3952-V601
Power backplane to SAS
backplanes / HDD ext. box
2 PSU Signal Cable 300 mm Y4027-V1
Power backplane to system
board
3 HDD / ODD Power Cable 410 mm Y4029-V201
SAS backplane to HDD
extension box or system
board
4 System Power Cable 500 mm Y3758-V9
Power backplane to system
board
5
Backup Drive Power
Cable
410 mm Y4029-V1
Backup drive to system
board or power backplane
6 ODD SATA Power Cable 410 mm Y3930-V601 ODD to SAS backplane
7
SAS Backup Drive
Power / Data cable
410 / 700
mm
Y3969-V401
SAS Backup drive to system
board connector SAS 1-4
8A
Slimline ODD SATA
Power Cable
400 mm Y3986-V302
ODD to system board or SAS
backplane
8B 500 mm Y3986-V305 ODD to SAS backplane
9
SAS Expander Board
Power Cable
300 mm Y4029-V101
SAS expander board to SAS
backplane
10
Front Panel Connector
Cable
400 mm Y4015-V1
Front panel module to
system board
11 Front LAN Cable 600 mm Y4025-V1
Server front to front LAN
board D2935
12 Front VGA Cable 500 mm Y3994-V101 Server front to system board
13 Intrusion Switch Cable
830 / 890
mm
Y3922-V121
Server side and front to
system board
14 LSD Cable 700 mm Y3718-V301 LSD to system board
Table 6: List of used cables
