610 Upgrade and Maintenance Manual TX300 S8 / RX350 S8
Front panel and external connectors
Ê Fold in the front panel module cover (2) until the left locking latch engages
with the front panel frame (3).
13.1.4 Installing the front panel module
13.1.4.1 Connecting cables to the front panel module
Ê If the front LAN connector is to be installed in the new front panel module,
install the front LAN cable as described in section "Installing the front LAN
connector" on page 618.
Ê If the front VGA connector is to be installed in the new front panel module,
install the front VGA cable as described in section "Installing the front VGA
connector" on page 632.
Figure 476: Connecting the front panel cable
Ê Connect the front panel cable to the new front panel module as shown.
