Fujitsu PRIMERGY RX350 S8

TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 199
Hard disk drives / solid state drives
7.2.5.2 Mounting order for 2.5-inch SAS 2.0 / SAS 3.0 HDDs / SSDs
Figure 104: Mounting order: 24x 2.5-inch HDDs / SSDs (8x SAS 3.0 / 16x SAS 2.0) (Rack)
Figure 105: Mounting order: 24x 2.5-inch HDDs / SSDs (8x SAS 3.0 / 16x SAS 2.0) (Tower)
HDD # Backplane type
1-8 (orange) 2 SAS 3.0 HDD / SSD backplanes
9-16 (white) 4 SAS 2.0 HDD / SSD backplanes
