12.7.3 Replacing the slimline ODD
12.7.3.1 Preliminary steps
Ê "Locating the defective server" on page 57
Ê "Removing backup and optical disk media" on page 129
Ê "Shutting down the server" on page 62
Ê "Disconnecting the server from the mains" on page 63
Ê When working on a rack-mounted server:
"Extending / removing the server from the rack" on page 64
Ê Open the side / top cover as described in section "Opening the server" on
page 68.
I Removing the front cover is not required in order to replace the
slimline ODD or LSP in the 2x 3.5-inch HDD extension box.
Ê "Removing the system air duct" on page 81
Ê "Removing the system fan holder" on page 330
12.7.3.2 Removing the 4x 3.5-inch HDD extension box
Ê Remove all cables from the 4x 3.5-inch HDD extension box backplane.
Ê Remove all cables from the slimline ODD.
Ê Remove the 4x 3.5-inch HDD extension box from the server as described in
section "Removing the 4x 3.5-inch HDD extension box" on page 299.
Upgrade and Repair Unit
(URU)
Average task duration:
10 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver
– Slotted screw driver (for bending in or out accessible drive
mounting brackets)
