8.3.4 Replacing the rear fan holder
8.3.4.1 Preliminary steps
Ê When working on a rack-mounted server:
"Extending / removing the server from the rack" on page 64
Ê Open the side / top cover as described in section "Opening the server" on
page 68.
Ê "Removing the system air duct" on page 81
Ê "Removing rear fan modules" on page 335
8.3.4.2 Removing the rear fan holder
Figure 230: Removing the rear fan holder (A)
Upgrade and Repair Unit
(URU)
Average task duration:
5minutes
Tools: tool-less
