Fujitsu PRIMERGY RX350 S8

TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 353
Expansion cards and backup units
9.2.1.3 Removing PCI slot bracket
Figure 240: Removing the PCI slot bracket (A)
Ê Press out on the locking latch to disengage the PCI slot bracket locking bar
(1, see close-up).
Ê Fold up (2) and remove (3) the PCI slot bracket locking bar.
