Fujitsu PRIMERGY RX350 S8

TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 69
Basic hardware procedures
Ê Open the locking lever (1). This will slide the top cover back disengaging the
locking mechanism (2).
Figure 13: Removing the top cover (rack server)
Ê Remove the top cover.
4.5.1.2 Removing the ID card
Figure 14: Removing the ID card (rack server)
