7.3.6 Installing 3.5-inch HDD modules
7.3.6.1 Preliminary steps
Ê When working on a tower server, open the HDD bay cover as described in
section "Removing accessible drive and HDD bay covers" on page 77.
Ê Locate the correct drive bay as described in section "3.5-inch HDD
configurations" on page 241.
Position
Logical drive
number
ServerView RAID Manager display name
[1] 0 HDD vendor name (1:0)
[2] 1 HDD vendor name (1:1)
[3] 2 HDD vendor name (1:2)
[4] 3 HDD vendor name (1:3)
[5] 4 HDD vendor name (1:4)
[6] 5 HDD vendor name (1:5)
[7] 6 HDD vendor name (1:6)
[8] 7 HDD vendor name (1:7)
[9] 8 HDD vendor name (1:8)
[10] 9 HDD vendor name (1:9)
[11] 10 HDD vendor name (1:10)
[12] 11 HDD vendor name (1:11)
Customer Replaceable Unit
(CRU)
Average task duration:
5minutes
Tools: tool-less
