Figure 257: Connecting the NCSI sideband cable to the system board
Ê Connect the loose end of the NCSI sideband cable to the system board:
9.3.1.5 Concluding steps
Ê "Installing the system air duct" on page 83
Ê "Closing the server" on page 98
Ê When working on a rack-mounted server:
"Mounting the server in the rack" on page 115
Ê Reconnect all external cables to the replaced expansion card.
Connector Cable
NC-SI NCSI sideband cable T26139-Y4015-V101
