8.3.4.3 Installing the rear fan holder
Figure 232: Mounting the rear fan holder (A)
Ê Lower the rear fan holder into the chassis.
Ê Fit the four hooks on the rear fan holder into the keyhole slots in the chassis.
Ê Press down on the rear fan holder until the four hooks lock in the narrow
ends of the keyhole slots (see close-up).
