12.2 Installing accessible drives
12.2.1 Preliminary steps
Ê "Shutting down the server" on page 62
Ê "Disconnecting the server from the mains" on page 63
Ê When working on a rack-mounted server:
"Extending / removing the server from the rack" on page 64
Ê "Opening the server" on page 68
I The front cover only needs to be removed in order to remove
accessible drive dummy covers.
Ê "Removing the system air duct" on page 81
Ê "Removing the system fan holder" on page 330
12.2.2 Removing accessible drive dummy covers
Ê Remove accessible drive filler covers from the required bays as described
in section "Accessible drive filler covers" on page 94.
Ê Remove accessible drive covers as described in section "Accessible drive
covers" on page 96.
Upgrade and Repair Unit
(URU)
Average task duration:
10 minutes
Tools: Slotted screw driver (for bending in or out accessible drive mounting
brackets)
