Fujitsu PRIMERGY RX350 S8

284 Upgrade and Maintenance Manual TX300 S8 / RX350 S8
Hard disk drives / solid state drives
7.4 HDD extension boxes
7.4.1 HDD extension box overview
7.4.1.1 8x 2.5-inch HDD extension box
Figure 192: 8x 2.5-inch HDD extension box - Rack version
Figure 193: 8x 2.5-inch HDD extension box - Tower version
I The 8x 2.5-inch HDD extension box occupies accessible drive bays 2
and 3.
Bays 2+3
Bays 2+3
