17.3.2 Connectors and indicators on the front panel
17.3.2.1 Front panel connectors
Figure 620: Front panel connectors
Pos. Component Reference
1 Video connector (VGA) (optional)
"Replacing the front VGA
connector" on page 641
2 Front LAN connector (optional)
"Replacing the front LAN
connector and board" on page 630
3 USB connectors (x2)
"Replacing the front panel module"
on page 601
