10.2.2 Installing a memory module
Ê Identify the correct memory slot according to the mounting order described
in section "Memory sequence" on page 468.
Figure 360: Installing memory modules (A)
Ê Press out the securing clip at each end of the memory module connector.
I For lack of space, it is necessary to remove the left rear fan (fan 5) in
order to install or remove memory modules in channels E and F. For
further information, please refer to section "Removing a rear fan
module" on page 336.
Figure 361: Installing memory modules (B)
