Fujitsu PRIMERGY RX350 S8

TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 285
Hard disk drives / solid state drives
7.4.1.2 2x 3.5-inch HDD extension box
Figure 194: 2x 3.5-inch HDD extension box - Rack version
Figure 195: 2x 3.5-inch HDD extension box - Tower version
I The 2x 3.5-inch HDD extension box occupies accessible drive bays 2
and 3.
Bays 2+3
Bays 2+3
