TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 601
13 Front panel and external
connectors
This chapter provides information on how to replace the front panel module and
optional front LAN connector board and front VGA connector.
Safety notes
V CAUTION!
● When inserting the front panel module into the server, ensure not to
pinch or strain any connected cables.
● Circuit boards and soldered parts of internal options are exposed and
can be damaged by static electricity. Always discharge static build-up
(e.g. by touching a grounded object) before handling electrostatic-
sensitive devices (ESDs)
● Do not touch the circuitry on boards or soldered parts. Hold circuit
boards by their metallic areas or edges.
● For further information, please refer to chapter "Important
information" on page 45.
13.1 Replacing the front panel module
Field Replaceable Unit
(FRU)
Average task duration:
15 minutes
Tools: tool-less
