9.5.3.3 Concluding steps
Ê "Installing the system air duct" on page 83
Ê "Closing the server" on page 98
Ê When working on a rack-mounted server:
"Mounting the server in the rack" on page 115
Ê "Connecting the server to the mains" on page 118
Ê If BitLocker functionality is used and has been disabled before starting the
maintenance task: "Resuming BitLocker functionality" on page 152
9.5.4 Replacing the SAS RAID controller
9.5.4.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 125
Ê "Disabling SVOM boot watchdog functionality" on page 127
Ê "Locating the defective server" on page 57
Ê "Shutting down the server" on page 62
Ê "Disconnecting the server from the mains" on page 63
Ê When working on a rack-mounted server:
"Extending / removing the server from the rack" on page 64
Ê Bring the server to its horizontal position.
Ê Open the side / top cover as described in section "Opening the server" on
page 68.
Ê "Removing the system air duct" on page 81
Ê Locate the defective expansion card using the onboard Local Diagnostic
LEDs as described in section "Onboard indicators and controls" on
page 779.
Upgrade and Repair Unit
(URU)
Average task duration:
15 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
