Hard disk drives / solid state drives
7.3.10.3 Removing the 4x 3.5-inch HDD front panel
Figure 181: Removing the 4x 3.5-inch HDD front panel (A)
Ê Remove four screws from the 4x 3.5-inch HDD front panel.
Figure 182: Removing the 4x 3.5-inch HDD front panel (B)
Ê Pull up on the 4x 3.5-inch HDD front panel to disengage it from the chassis.
Ê Remove the 4x 3.5-inch HDD front panel.
