14.3 Trusted Platform Module (TPM)
This section provides information on how to install, remove or replace the
Trusted Platform Module (TPM).
14.3.1 Installing the TPM board
14.3.1.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 125
Ê "Locating the defective server" on page 57
Ê "Shutting down the server" on page 62
Ê "Disconnecting the server from the mains" on page 63
Ê When working on a rack-mounted server:
"Extending / removing the server from the rack" on page 64
Ê Open the side / top cover as described in section "Opening the server" on
page 68.
Ê "Removing the system air duct" on page 81
Field Replaceable Unit
(FRU)
Average task duration:
10 minutes
Tools: – Phillips PH2 / (+) No. 2 screw driver
– Bit screw driver
– TPM bit insert
(
*
)
(
*
)
For the Japanese market:
– TPM module fixing tool (S26361-F3552-L909)
