Fujitsu PRIMERGY RX350 S8

TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 759
Cabling
16.2.23 SAS 2.0 BBU / FBU cabling
Figure 599: SAS 2.0 BBU / FBU cabling
SAS Controller 1
(PCI Slot 10)
MLC 1
MLC 2
BBU / FBU
SAS Controller 2
(PCI Slot 2)
MLC 1
MLC 2
BBU / FBU
External SAS
Controller 3
(PCI Slot 3)
MLC 1
MLC 2
BBU / FBU
External SAS
Controller 3
(PCI Slot 8)
MLC 1
MLC 2
BBU / FBU
BBU / FBU 2
BBU / FBU 1
BBU / FBU 1
BBU / FBU 3
22/23
22/23
22/23
22/23
BBU / FBU support is not possible if BBU / FBU 1
is already occupied by SAS controller 2.
This configuration is only possible with CPU 2 installed.
