Basic hardware procedures
4.9.2 Closing the accessible drive locking bar
4.9.2.1 Tower servers
Figure 40: Closing the accessible drive locking bar
Ê Close the locking bar until it locks in place (see close-up).
4.9.2.2 Rack servers
Figure 41: Closing the accessible drive locking bar (rack systems)
Ê Fold in the locking bar (1) until it locks in place (2,see close-up).
