542 Upgrade and Maintenance Manual TX300 S8 / RX350 S8
Accessible drives
2.5-inch HDD configurations (4 SAS backplanes, up to 8 HDDs)
2.5-inch HDD configurations (6/8 SAS backplanes, up to 16/24 HDDs)
Ê Connect the USB and power cables according to your configuration as
shown in the tables above.
Cable
(T26139-)
Cabling
list no.
from to
Cabling
plan
USB 2.0 cable
Y3973-V96
21A
USB backup drive
(Type B connector)
System board
connector USB INT 1
(6-pin connector)
16.2.1
USB 3.0 cable
Y4039-V100
21B
USB 3.0 PCI card
(Type A connector)
Backup drive power
cable
Y4029-V1
5
USB backup drive
(PATA connector)
2.5-inch HDD
backplane 2
connector X9
(4-pin connector)
16.2.11
Cable
(T26139-)
Cabling
list no.
from to
Cabling
plan
USB 2.0 cable
Y3973-V96
21A
USB backup drive
(Type B connector)
System board
connector USB INT 1
(6-pin connector)
16.2.1
USB 3.0 cable
Y4039-V100
21B
USB 3.0 PCI card
(Type A connector)
Backup drive power
cable
Y4029-V1
5
USB backup drive
(PATA connector)
2.5-inch HDD
backplane 4
connector X9
(4-pin connector)
16.2.12
