Fujitsu PRIMERGY RX350 S8

190 Upgrade and Maintenance Manual TX300 S8 / RX350 S8
Hard disk drives / solid state drives
SAS cabling with SAS 2.0 controller and two SAS 3.0 backplanes
I This cabling configuration includes Out-of-Band monitoring with
SAS 2.0 RAID controllers D2616 and D2607.
SAS cabling with SAS 3.0 controller and two SAS 3.0 backplanes
Power cabling
Cable
(T26139-)
Cabling
list no.
from to
Cabling
plan
SAS 2.0 / 3.0 cable
Y4040-V14
28
Connector MLC 1 on
SAS 2.0 controller 1
SAS 3.0 backplane 1
connector X5
16.2.13
SAS 2.0 / 3.0 cable
Y4040-V14
28
Connector MLC 2 on
SAS 2.0 controller 1
SAS 3.0 backplane 2
connector X5
SAS 3.0 Out-of-Band
cable Y4015-V601
29 System board
SAS 3.0 backplane
1/2 connectors X11
Cable
(T26139-)
Cabling
list no.
from to
Cabling
plan
SAS 3.0 cable
Y4040-V8
27
Connector MLC 1 on
SAS 3.0 controller 1
SAS 3.0 backplane 1
connector X5
16.2.14
SAS 3.0 cable
Y4040-V8
27
Connector MLC 2 on
SAS 3.0 controller 1
SAS 3.0 backplane 2
connector X5
Cable
(T26139-)
Cabling
list no.
from to
Cabling
plan
HDD power cable
Y3952-V601
1
Power backplane
connector X21
SAS backplane 1
connector
X6 (SAS 2.0) /
X10 (SAS 3.0)
(HDDs 1, 3, 5, 7)
Cable connector P2
16.2.11
SAS backplane 2
connector
X6 (SAS 2.0) /
X10 (SAS 3.0)
(HDDs 2, 4, 6, 8)
Cable connector P1
