Fujitsu PRIMERGY RX350 S8

TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 203
Hard disk drives / solid state drives
Power cabling
Cable
(T26139-)
Cabling
list no.
from to
Cabling
plan
HDD power cable
Y3952-V601
1
Power backplane
connector X21
SAS backplane 1
connector
X6 (SAS 2.0) /
X10 (SAS 3.0)
(HDDs 1, 7, 13, 19)
Cable connector P2
16.2.12
SAS backplane 2
connector
X6 (SAS 2.0) /
X10 (SAS 3.0)
(HDDs 2, 8, 14, 20)
Cable connector P1
SAS backplane 3
connector
X6 (SAS 2.0) /
X10 (SAS 3.0)
(HDDs 3, 9, 15, 21)
Cable connector P4
SAS backplane 4
connector
X6 (SAS 2.0) /
X10 (SAS 3.0)
(HDDs 4, 10, 16, 22)
Cable connector P3
HDD / ODD power
cable
Y4029-V201
3
SAS backplane 3
connector
X9 (SAS 2.0) /
X14 (SAS 3.0)
SAS backplane 5
connector X8
(HDDs 5, 11, 17, 23)
16.2.12
HDD / ODD power
cable
Y4029-V201
3
SAS backplane 4
connector
X9 (SAS 2.0) /
X14 (SAS 3.0)
SAS backplane 6
connector X8
(HDDs 6, 12, 18, 24)
