Hard disk drives / solid state drives
With SAS expander board and two SAS controllers
Position
Logical drive
number
ServerView RAID Manager display name
[1] 0 HDD vendor name (0) Ctrl (0)
[2] 1 HDD vendor name (1) Ctrl (0)
[3] 2 HDD vendor name (2) Ctrl (0)
[4] 3 HDD vendor name (3) Ctrl (0)
[5] 4 HDD vendor name (4) Ctrl (0)
[6] 5 HDD vendor name (5) Ctrl (0)
[7] 6 HDD vendor name (6) Ctrl (0)
[8] 7 HDD vendor name (7) Ctrl (0)
[9] 0 HDD vendor name (1:0) Ctrl (1)
[10] 1 HDD vendor name (1:1) Ctrl (1)
[11] 2 HDD vendor name (1:2) Ctrl (1)
[12] 3 HDD vendor name (1:3) Ctrl (1)
[13] 4 HDD vendor name (1:4) Ctrl (1)
[14] 5 HDD vendor name (1:5) Ctrl (1)
[15] 6 HDD vendor name (1:6) Ctrl (1)
[16] 7 HDD vendor name (1:7) Ctrl (1)
[17] 8 HDD vendor name (1:8) Ctrl (1)
[18] 9 HDD vendor name (1:9) Ctrl (1)
[19] 10 HDD vendor name (1:10) Ctrl (1)
[20] 11 HDD vendor name (1:11) Ctrl (1)
[21] 12 HDD vendor name (1:12) Ctrl (1)
[22] 13 HDD vendor name (1:13) Ctrl (1)
[23] 14 HDD vendor name (1:14) Ctrl (1)
[24] 15 HDD vendor name (1:15) Ctrl (1)
