Fujitsu PRIMERGY RX350 S8

TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 367
Expansion cards and backup units
Figure 252: Connecting the NCSI sideband cable to the Modular LAN controller
Ê Connect the NCSI sideband cable to the Modular LAN controller:
I For a complete cabling overview, please refer to section "Cabling
overviews" on page 738.
Connector Cable
20-pin connector NCSI sideband cable T26139-Y4015-V101
